Place of Origin: | China |
Brand Name: | URILIC |
Certification: | CE,UL |
Model Number: | USES-3KW-5KW |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | Negotiation |
Packaging Details: | Plywood box |
Delivery Time: | 5-15 days |
Payment Terms: | T/T |
Supply Ability: | 1000PCS/month |
Product Name: | Off Grid Lithium Battery | Output Power: | 3KW, 5KW |
---|---|---|---|
Cycle Life: | >4000 | Battery Capacity: | 4.8~14.4KWh |
Size: | 560*320*1235mm | Weight: | 250kg |
Highlight: | off grid lithium ion battery,lifepo4 lithium battery |
43KW to 5KW Off Grid Lithium Battery Power Supply Storage Energy System
USES-3KW-5KW is able to store clean energy generated by solar PV with lithium battery, which allows maximum self-consumption. Its soft-toned appearance and less occupied area merges perfectly with home environment.
USES-3KW-5KW combines PV power generation, energy storage and power supply as a family power supply integration solution. The system provides access to economic solar energy and stores extra energy, turning families into mini-power stations and ensures continuous clean energy supply.
Product Details:
Item | USES-3KW | USES-5KW | |||||||||||||
System | |||||||||||||||
Output Power | 3KW | 5KW | |||||||||||||
Battery Capacity | 4.8/7.2/9.6/12/14.4KWh | 9.6/12/14.4KWh | |||||||||||||
Single Phase/3 Phase | Single phase | ||||||||||||||
Shifting Time | <20ms(on-grid to off-grid,off-grid to on-grid) | ||||||||||||||
LCD Screen | English Script | ||||||||||||||
Communication | Ethernet/Dry contact/CAN/RS232/Wifi | ||||||||||||||
Cooling | Natural air-cooling | ||||||||||||||
Work Temperature | -10℃~+50℃ | ||||||||||||||
IP | IP21 | ||||||||||||||
Noise | <40dB | ||||||||||||||
Dimension(L*W*H) | 560*320*1235mm | 560*320*1235mm | |||||||||||||
Weight | 250KG | 250KG | |||||||||||||
System Design Life | 20 years | ||||||||||||||
Battery | |||||||||||||||
Battery Type | Lithium battery | ||||||||||||||
Cycle Life | >4000 | ||||||||||||||
Quality Assurance | 10 years | ||||||||||||||
Module | |||||||||||||||
Nominal Voltage | 48V | 48V | |||||||||||||
Maximum Charge Current | 50A | 100A | |||||||||||||
Maximum Discharge Current | 100A | 200A | |||||||||||||
Maximum Charge Power | 3KW | 5KW | |||||||||||||
PV System | |||||||||||||||
Maximum Voltage Allowed | 550V | ||||||||||||||
Start voltage | 125V | ||||||||||||||
MPPT Work Voltage | 125V~530V | ||||||||||||||
MPPT Efficiency | 99.9% | ||||||||||||||
Maximum Input Power | 3300W | 5000W | |||||||||||||
Maximum Input Current | 12A | 12A/12A | |||||||||||||
MPPT Passageway | 1 | 2 | |||||||||||||
Conversion Rate | 97.6% |
Key Features:
When you choose URILIC, you cling to high quality and high reliability. USES has a design life of up to 20 years, the cell of which is from well-known cell manufacturing enterprises. All the cells run thorough tests before assembled into batteries, such as cycle life tests, combustion tests, over-charge tests, over-discharge tests, short circuit tests, acupuncture tests and so on. At the same time, our installation staffs are certified professionals. With 10 years of quality assurance, you can avoid a lot of troubles.
Multiple and Wide Application:
Our advantage:
URILIC is the world's leading manufacturer and marketer of energy-supply systems, primarily for wind and light energy front-end power generation, back-end energy storage applications, and product range from intelligent integration of new energy peripheral products.
URILIC is constantly striving to become China's leading OEM/ODM manufacturer. To this end, URILIC is committed to working with world-class brands to deliver on our promises and provide partners with complete power solutions.
